Geberit Cistern Wall Hung Sigma 8cm (110.798.00.1)

Application purposes

• For masonry walls
• For installation in part or room-height pre-wall installations
• For wall-hung WCs with connection dimensions in accordance with EN 33:2011
• For single flush, dual flush, or stop-and-go flush

Characteristics

• Range 2016
• Powder-coated installation frame
• Mounting frame with four fastening brackets
• Pre-mounted direct plastering netting
• Fixing bracket coordinated with solid walls with 8 or 12 cm wall thickness
• Fastening for connection bend can be mounted without tools from the front
• Concealed cistern with front actuation

Scope of delivery

• Water supply connection Rp 1/2″ – R 1/2″, compatible with MF, with
• integrated angle stop valve and handwheel
• Protection box for service opening
• 4 fixing brackets
• Connection set for WC, ø 90 mm
• Connection bend 90° made of PE-HD, ø 90 mm
• Adapter socket made of PE-HD, ø 90 / 110 mm
• 2 protection plugs
• 2 threaded rods M12
• Fastening material
